Saturday, March 10, 2007

1912 Maxwell

Here is the first of the many motorcars that will be featured on this site. This neat little roadster was quite popular in it’s time. This model is fully equipped, loaded with options, including a roof and even a windshield. Notice the Prest-O-Lite tank on the running board which powered the headlights.

Free Image Hosting at www.picturetrail.com

Click photo to enlarge

Specifications:

[Price – 1,150] _ [Body - roadster] _ [Seating - 2] _ [H.P. - 30]

[Type Motor – 4-cycle] _ [Cylinders - 4] _ [Cylinder Casting - single]
[Bore and Stroke – 4 -1/4 x 4 - 1/4] _ [Ignition – magneto and battery]

[Clutch – multi-disc] _ [Type of gear -progressive] _ [Forward speeds - 3]

[Final drive - shaft] _ [No. of universals - 2] _ [Rear Axle – semi-floating]
[Rear Axle bearings - roller] _ [Front Axle - tubular]

[Service brake - contracting] _ [Emergency brake - expanding]

[Wheel base - 110] _ [Front tire – 34 x 4] _ [Rear tire – 34 x 4]

[Weight – 2,100]
